0-10V Universal Sensor - Wi-Fi OTA (B16-200-OTA, B16-500-OTA)

Overview

A 0-10V temperature sensor for monitoring environmental conditions such as humidity, temperature, and differential pressure in settings like medical research, food storage/transit, and data centers. Available in single-band (2.4 GHz) and dual-band (2.4 GHz / 5 GHz) connectivity. A high-speed wireless module with PEAPv0 enterprise security that collects, stores, and transmits data, sending critical alerts to email, phone, pager, and more. Features push buttons for real-time readings, battery and AC power, and enterprise-wide scalability, with a three-year device warranty and installation support.

Specifications

Voltage

0-10V

Accuracy

+/-0.5% (+/-50mV)

Ambient Operating Range

0C to 75C (32F to 167F); Up to 95% RH

Memory

Unlimited Cloud Memory; On-transmitter Buffer Storage (4000 Readings)

Alarms

Onboard Visual and Audible Alarms; 24/7 Alert Notifications through the Cloud

RF Frequency

2.4 to 2.497 GHz

Radio Protocol

IEEE802.11 b/g/n Compatible 54Mbit/sec

Enterprise Security

PEAPv0 with EAP-MSCAPv2 (PEAP)

Housing

ABS Plastic Enclosure with Silicon Rubber Covers and Open Ports

Mounting

Zip Tie Mount Hooked with Screw Holster Wall Mount

Power Supply

(4) 1.5V AA Batteries (Lithium or Alkaline); Optional AC/DC Power Supply (UL Certified)

Battery Life

1 Year

Dimensions

Height 4.25" (108mm); Width 3.88" (98mm); Length 1.38" (35mm)

LDAP

Single Sign-on Capability

Certificates

Device-level Certificates

Warranty

3-Year Warranty
