Thermal Probe TA10C
Thermal flow sensors in probe design with shaft diameter 10/18 mm and transducer UTA integrated in the sensor shaft.
- Supplied and supported by GTi in Thailand
- Calibration certificate on delivery
- Selection, installation and commissioning help
Overview
Examples of application: in clean rooms, for mounting on ceilings or walls.
Probe material: stainless steel.
Suitable for fixed measuring of standard velocity v [m/s], standard flow rate NV/t [m³/h] and standard volume NV [m³].
Specifications
- Measuring range
- 0.2 ... 1 / 2 / 20 m/s
- Pressure resistance
- up to 16 bar / 1.6 MPa
- Media temperature
- -10 ... +80 °C
- Media
- air / gases
- Type of protection
- ATEX category 3G and 3D (zone 2 and 22) (optional)
- Sensor output
- analog output flow 4-20 mA / relay for quantity pulse / RS232 interface
Documents & Downloads
Manuals, data sheets and approvals from the manufacturer. Ask us if you need a document that is not listed.
